Működési hőmérséklet: -40°C – 80°C.
Az MBT kötődobozok kiváló tulajdonságokkal rendelkeznek elektronikai és villamos alkatrészek, valamint beltéri alkalmazások komplett vezérlőrendszereinek telepítéséhez.
Az MBT kötődobozok mechanikailag sokféleképpen megmunkálhatók, így gyakorlatilag nincsenek korlátai az egyedi felületkialakításnak – beleértve a szitanyomást és a membrános billentyűzeteket is.
A burkolatok szürke vagy átlátszó fedéllel (K) érhetők el.
• Fedél anyaga: ABS
• Alap anyaga: ABS
• Tömítés anyaga: poliuterén
• Csavarok anyaga: rozsdamentes acél V2A
• Szilikonmentes: Igen
• Halogénmentes: Igen
• UV-álló: Nem
| Cikkszám | Típus | Hosszúság | Szélesség | Magasság | |||||
| 0401100100 | MBT 050504 | 52 mm | 50 mm | 35 mm |  | ||||
| 0401100200 | MBT 050504 | 65 mm | 50 mm | 35 mm | | ||||
| 0401100400 | MBT 060505 | 65 mm | 50 mm | 45 mm | | ||||
| 0401100500 | MBT 060545 | 65 mm | 50 mm | 45 mm | | ||||
| 0401100600 | MBT 060555 | 65 mm | 50 mm | 55 mm | | ||||
| 0401100700 | MBT 060603 | 58 mm | 64 mm | 37 mm | | ||||
| 0401100800 | MBT 090603 | 98 mm | 64 mm | 37 mm | | ||||
| 0401101000 | MBT 080805 | 82 mm | 80 mm | 55 mm | | ||||
| 0401101200 | MBT 080807 | 82 mm | 80 mm | 65 mm | | ||||
| 0401101300 | MBT 080809 | 82 mm | 80 mm | 85 mm | | ||||
| 0401101400 | MBT 080810 | 82 mm | 80 mm | 95 mm | | ||||
| 0401101500 | MBT 128035 | 120 mm | 80 mm | 36 mm | | ||||
| 0401101600 | MBT 128040 | 120 mm | 80 mm | 41 mm | | ||||
| 0401101700 | MBT 128045 | 120 mm | 80 mm | 47 mm | | ||||
| 0401101900 | MBT 128050 | 120 mm | 80 mm | 50 mm | | ||||
| 0401102100 | MBT 128055 | 120 mm | 80 mm | 55 mm | | ||||
| 0401102300 | MBT 128060 | 120 mm | 80 mm | 60 mm | | ||||
| 0401102330 | MBT 128060 | 120 mm | 80 mm | 60 mm | | ||||
| 0401102340 | MBT 128065 | 120 mm | 80 mm | 65 mm | | ||||
| 0401102500 | MBT 128070 | 120 mm | 80 mm | 70 mm | | ||||
| 0401102550 | MBT 128070 | 120 mm | 80 mm | 70 mm | | ||||
| 0401102700 | MBT 128080 | 120 mm | 80 mm | 80 mm | | ||||
| 0401102750 | MBT 128080 | 120 mm | 80 mm | 80 mm | | ||||
| 0401102900 | MBT 128085 | 120 mm | 80 mm | 85 mm | | ||||
| 0401103100 | MBT 128090 | 120 mm | 80 mm | 90 mm | | ||||
| 0401103300 | MBT 128010 | 120 mm | 80 mm | 100 mm | | ||||
| 0401103610 | MBT 168035 | 160 mm | 80 mm | 37 mm | | ||||
| 0401103500 | MBT 168055 | 160 mm | 80 mm | 55 mm | | ||||
| 0401103700 | MBT 168060 | 160 mm | 80 mm | 60 mm | | ||||
| 0401103800 | MBT 168085 | 160 mm | 80 mm | 85 mm | | ||||
| 0401103900 | MBT 168090 | 160 mm | 80 mm | 90 mm | | ||||
| 0401104000 | MBT 208055 | 200 mm | 80 mm | 55 mm | | ||||
| 0401109700 | MBT 208011 | 200 mm | 80 mm | 110 mm | | ||||
| 0401107510 | MBT 248055 | 240 mm | 80 mm | 55 mm | | ||||
| 0401104200 | MBT 121255 | 122 mm | 120 mm | 55 mm | | ||||
| 0401104400 | MBT 121275 | 122 mm | 120 mm | 75 mm | | ||||
| 0401104600 | MBT 121285 | 122 mm | 120 mm | 85 mm | | ||||
| 0401104800 | MBT 121211 | 122 mm | 120 mm | 105 mm | | ||||
| 0401104900 | MBT 161255 | 160 mm | 120 mm | 55 mm | | ||||
| 0401105000 | MBT 161270 | 160 mm | 120 mm | 70 mm | | ||||
| 0401105100 | MBT 161275 | 160 mm | 120 mm | 75 mm | | ||||
| 0401105200 | MBT 161290 | 160 mm | 120 mm | 90 mm | | ||||
| 0401105300 | MBT 161212 | 160 mm | 120 mm | 120 mm | | ||||
| 0401105400 | MBT 161214 | 160 mm | 120 mm | 140 mm | | ||||
| 0401105600 | MBT 201255 | 200 mm | 120 mm | 55 mm | | ||||
| 0401105700 | MBT 201270 | 200 mm | 120 mm | 70 mm | | ||||
| 0401105900 | MBT 201275 | 200 mm | 120 mm | 75 mm | | ||||
| 0401106100 | MBT 201290 | 200 mm | 120 mm | 90 mm | | ||||
| 0401106900 | MBT 241270 | 240 mm | 120 mm | 70 mm | | ||||
| 0401106800 | MBT 241210 | 240 mm | 120 mm | 100 mm | | ||||
| 0401106200 | MBT 201555 | 200 mm | 150 mm | 55 mm | | ||||
| 0401106300 | MBT 201575 | 200 mm | 150 mm | 75 mm | | ||||
| 0401106400 | MBT 201580 | 200 mm | 150 mm | 80 mm | | ||||
| 0401106500 | MBT 201510 | 200 mm | 150 mm | 100 mm | | ||||
| 0401106600 | MBT 201511 | 200 mm | 150 mm | 105 mm | | ||||
| 0401106700 | MBT 201513 | 200 mm | 150 mm | 125 mm | | ||||
| 0401108200 | MBT 341555 | 340 mm | 150 mm | 55 mm | | ||||
| 0401108300 | MBT 341580 | 340 mm | 150 mm | 75 mm | | ||||
| 0401108500 | MBT 341510 | 340 mm | 150 mm | 100 mm | | ||||
| 0401108600 | MBT 341512 | 340 mm | 150 mm | 120 mm | | ||||
| 0401105500 | MBT 161665 | 160 mm | 160 mm | 65 mm | | ||||
| 0401107030 | MBT 241670 | 240 mm | 160 mm | 70 mm | | ||||
| 0401107000 | MBT 241690 | 240 mm | 160 mm | 90 mm | | ||||
| 0401107100 | MBT 241612 | 240 mm | 160 mm | 120 mm | | ||||
| 0401107200 | MBT 251655 | 250 mm | 160 mm | 55 mm | | ||||
| 0401107300 | MBT 251685 | 250 mm | 160 mm | 85 mm | | ||||
| 0401107400 | MBT 251690 | 250 mm | 160 mm | 90 mm | | ||||
| 0401107500 | MBT 251611 | 250 mm | 160 mm | 115 mm | | ||||
| 0401107600 | MBT 251612 | 250 mm | 160 mm | 120 mm | | ||||
| 0401107700 | MBT 251615 | 250 mm | 160 mm | 150 mm | | ||||
| 0401108700 | MBT 362015 | 360 mm | 200 mm | 150 mm | | ||||
| 0401107800 | MBT 302365 | 300 mm | 230 mm | 65 mm | | ||||
| 0401107900 | MBT 302385 | 300 mm | 230 mm | 85 mm | | ||||
| 0401108000 | MBT 302311 | 300 mm | 230 mm | 110 mm | | ||||
